Condition: For parts or not working

Condition Unknown, Military Surplus

RTX 4063996, 4063996B, 4730012167465, Flange to Tube Tee RTX 4063996, 4063996B, 4730012167465, Flange to Tube Tee

RTX

4063996, 4063996B

4730012167465

Flange to Tube Tee

Technical informationNameValueTHREAD CLASS3A FIRST ENDTHREAD CLASS3A SECOND ENDBOLT HOLE QUANTITY1 THIRD ENDEND ITEM IDENTIFICATIONENGINE, AIRCRAFT, F100-PW-200 (F-16A/B/C/D)CONNECTION STYLEFLARED (TUBE) SECOND ENDCONNECTION STYLEFLARED (TUBE) FIRST ENDLEG LENGTH1.060 INCHES NOMINAL FIRST ENDLEG LENGTH1.060 INCHES NOMINAL SECOND ENDLEG LENGTH1.905 INCHES NOMINAL THIRD ENDFLANGE SHAPEOVAL WITH HOLES THIRD ENDCONNECTION TYPEFLANGE THIRD ENDCONNECTION TYPETHREADED EXTERNAL TUBE FIRST ENDCONNECTION TYPETHREADED EXTERNAL TUBE SECOND ENDNOMINAL THREAD SIZE0.5625 INCHES SECOND ENDNOMINAL THREAD SIZE0.750 INCHES FIRST ENDSEAT ANGLE37.0 DEGREES FIRST ENDSEAT ANGLE37.0 DEGREES SECOND ENDFLOW ANGLE45.0 DEGREESCRITICALITY CODE JUSTIFICATIONFEATNOMINAL THICKNESS0.075 INCHES THIRD ENDBOLT HOLE NOMINAL DIAMETER0.221 INCHES THIRD ENDBOLT CIRCLE NOMINAL DIAMETER0.800 INCHES THIRD ENDFLANGE FACE DESIGNRECESSED STRAIGHT THIRD ENDRECESS NOMINAL DEPTH0.400 INCHES THIRD ENDSPECIAL FEATURESU/O F100-PW-200 ENG;WEAPON SYSTEM ESSENTIALMATERIALSTEEL CORROSION RESISTING OVERALLMATERIAL DOCUMENT AND CLASSIFICATIONAMS 5646 ASSN STD SINGLE MATERIAL RESPONSE OVERALLTHREAD SERIES DESIGNATORUNIFIED NATIONAL JOINT FINE (UNJF) FIRST ENDTHREAD SERIES DESIGNATORUNIFIED NATIONAL JOINT FINE (UNJF) SECOND END

490-C-O-04397-000000
