Condition: New – Open box

–

Rockwell
542-4556-002
3020007133797
Spur Gear
Sold Separately

DISCONTINUED WITHOUT REPLACEMENT

Name Value BODY STYLE PLAIN, SOLID PITCH DIAMETER 0.5313 INCHES NOMINAL TEETH QUANTITY 84 BORE STYLE PLAIN BOTH ENDS NOMINAL OUTSIDE DIAMETER 0.563 INCHES TOOTH FORM STANDARD PRESSURE ANGLE 20.0000 DEGREES NOMINAL DISTANCE BETWEEN BODY FACE AND PROTRUDING HUB END 0.219 INCHES FIRST END FACE NOMINAL WIDTH 0.109 INCHES BORE NOMINAL DIAMETER 0.156 INCHES BOTH ENDS HUB STYLE DESIGNATOR SPLIT FIRST END HUB NOMINAL DIAMETER 0.249 INCHES FIRST END CLAMPING SURFACE NOMINAL LENGTH 0.1790 INCHES FIRST END MATERIAL ALUMINUM ALLOY 2024 OVERALL MATERIAL DOCUMENT AND CLASSIFICATION QQ-A-225/6,T4 FED SPEC SINGLE MATERIAL RESPONSE OVERALL SURFACE TREATMENT ANODIZE OVERALL STYLE DESIGNATOR PROTRUDING HUB FSC APPLICATION DATA RADIO SETS RADIO,EXCEPT NAVIGATION AND HOME TYPES,AIRBORNE

Unless otherwise noted, this listing is for one item per purchase

4-C-C-02401-000000
