Condition: New – Open box

–

Parker-Hannifin
111299-16-0240
4720007985010
Hose Assembly

Name Value CROSS-SECTIONAL SHAPE STYLE ROUND THREAD CLASS 2B 2ND END THREAD CLASS 2B 1ST END THREAD DIRECTION RIGHT-HAND 2ND END THREAD DIRECTION RIGHT-HAND 1ST END INSIDE DIAMETER 0.875 INCHES NOMINAL TEMP RATING -40.0 DEG FAHRENHEIT AND 250.0 DEG FAHRENHEIT SINGLE RESPONSE OUTSIDE DIAMETER 1.230 INCHES NOMINAL MINIMUM INSIDE BENDING RADIUS 7.380 INCHES CONNECTION STYLE SWIVEL NUT WITH LOOSE OR INTEGRAL CLINCH SLEEVE 1ST END CONNECTION STYLE SWIVEL NUT WITH LOOSE OR INTEGRAL CLINCH SLEEVE 2ND END END CONNECTION DESIGN ELBOW 2ND END END CONNECTION DESIGN STRAIGHT 1ST END CONNECTION TYPE THREADED INTERNAL TUBE 1ST END CONNECTION TYPE THREADED INTERNAL TUBE 2ND END THREAD QUANTITY PER INCH 12 1ST END THREAD QUANTITY PER INCH 12 2ND END BURST TEST PRESSURE 3200.0 POUNDS PER SQUARE INCH LAYER COMPOSITION AND LOCATION 1ST LAYER BRAIDED FIBER AND 2ND LAYER BRAIDED STEEL WIRE AND OUTER LAYER RUBBER IMPREGNATED BRAIDED FABRIC MAXIMUM OPERATING PRESSURE 800.0 POUNDS PER SQUARE INCH NOMINAL THREAD SIZE 1.312 INCHES 2ND END NOMINAL THREAD SIZE 1.312 INCHES 1ST END SEAT ANGLE 12.0 DEGREES 1ST END SEAT ANGLE 12.0 DEGREES 2ND END HYDROSTATIC TEST PRESSURE 1600.0 POUNDS PER SQUARE INCH FLOW ANGLE 90.0 DEGREES 2ND END INSIDE SURFACE CONDITION SMOOTH MEASURING METHOD AND LENGTH 24.000 INCHES NOMINAL OVERALL MEDIA FOR WHICH DESIGNED FUEL/OIL, HYDROCARBON SINGLE RESPONSE SUPPLEMENTARY FEATURES THIS ITEM HAS BEEN REVIEWED FOR ASBESTOS MATERIAL. THE CURRENT APPROVED SOURCE, 98441, HAS INDICATED THEIR PART NUMBER CONTAINED ASBESTOS PRIOR TO 1984. THEY CONTINUE TO MANUFACTURE THE SAME PART NUMBER WITHOUT ASBESTOS MATERIAL AFTER 1984 THREAD SERIES DESIGNATOR UN 2ND END THREAD SERIES DESIGNATOR UN 1ST END

Unless otherwise noted, this listing is for one item per purchase

134-B-01609-000000
