Condition: New

OSHKOSH 122760C 3040012138553 SHAFT COLLAR

–

OSHKOSH
122760C
3040012138553
SHAFT COLLAR

Name Value CHAMFER ANGLE IN DEG 45.0 OUTSIDE DIAMETER 7.250 INCHES NOMINAL THICKNESS 1.811 INCHES NOMINAL BORE DIAMETER 5.5025 INCHES NOMINAL LARGEST DIAMETER LENGTH 1.071 INCHES NOMINAL SURFACE FINISH AND LOCATION 200 MICROINCHES OVERALL SPECIAL FEATURES BORE INTERNALLY SPLINED;SPLINES 30 DEG PRESSURE ANGLE,6/12 PITCH,5.6667 IN. PITCH DIA,5.5025 IN. MINOR DIA,5.8795 IN.MAJOR DIA,GR00VE 0.508 IN. WIDE,0.995 IN. DEEP;ROCKWELL C 58.0 AND 62.0 MATERIAL STEEL PROPRIETARY CHARACTERISTICS PACS STYLE DESIGNATOR ROUND W/DOUBLE CHAMFER MATERIAL STEEL STYLE DESIGNATOR A4 ROUND W/DOUBLE CHAMFER

Unless otherwise noted, this listing is for one item per purchase…

143-B 01101-000000
