Pipe Flange
21133750
810-4715319
Fig 2-C
4730-01-463-6231
>NEW

ABKG BOLT CIRCLE DIAMETER 11.750 INCHES NOMINAL ABKK FLANGE DIAMETER 13.500 INCHES NOMINAL ABNM THICKNESS 0.938 INCHES NOMINAL ABXP SOCKET DIAMETER 8.682 INCHES NOMINAL ABXV BORE DIAMETER 7.981 INCHES NOMINAL AECS BOLT HOLE QUANTITY 8 AHNX BOLT HOLE DIAMETER 0.875 INCHES NOMINAL AJEG NECK HEIGHT 1.000 INCHES NOMINAL AJEM FLANGE SECTION STYLE PLAIN FACE, SOCKET BRAZING NECK W/O BRAZING RING AKWE FACE SEATING SURFACE CONDITION MACHINED CQCJ MAXIMUM OPERATING PRESSURE AND MEDIA FOR WHICH DESIGNED 200.0 POUNDS PER SQUARE INCH WATER AND 200.0 POUNDS PER SQUARE INCH GAS AND 200.0 POUNDS PER SQUARE INCH OIL AND 200.0 POUNDS PER SQUARE INCH STEAM CRWH MAXIMUM OPERATING TEMP AND MEDIA FOR WHICH DESIGNED 425.0 DEG FAHRENHEIT STEAM AND 200.0 DEG FAHRENHEIT WATER AND 200.0 DEG FAHRENHEIT GAS AND 200.0 DEG FAHRENHEIT OIL MATT MATERIAL COPPER MDCL MATERIAL DOCUMENT AND CLASSIFICATION ASME B16.5 ASSN STD SINGLE MATERIAL RESPONSE STYL STYLE DESIGNATOR ROUND, ONE BOLT HOLE CIRCLE
